Digital Torque Wrenches【Bluetooth】

WQ(-BT) series - Digital Bluetooth Torque Wrench & Electronic Torque Wrench

WQ(-BT) series (4.5~1000 Nm)

Features

Bluetooth Additional Features:.
★ Access historical data at any time through Bluetooth connection to the mobile phone.(View up to 1000 records)
★ Connect via Type-C to save data on the computer.
★ Free download of the app (iOS、Android ), and computer software.
★ Lock the wrench via the app, preventing accidental pressing by users..
★ The app allows selecting auto-shutdown time (1 min, 2 min, 5 min, 10 min).

Built-in features
1. Use the piezoelectric effect converted into accurately torque value.
2. Two modes : F(Track) / K(Peak).
3. Warning function : Beep, LED indicator. ( When reach the torque setting value 80%)
4. Vibration function : When reach the torque setting value 90%.
5. Four torque units are available : N-m, ft-lb, in-lb, kgf-cm.
6 .Can store 30 memory setting values.
7.Recording usage frequency and the historical maximum torque.
※※ Suggested accessories: Socket and Bit Socket. ※※
➤Content : Provide storage steel box x1, Certificate of calibration report (Using ISO specification) x1, Operator’s menu(Bilingual) x1, USB insert(Type C)

Catalog Resource Inquiry ☑️

　Unit: mm [※1 kgf ≒ 10 N]SPECIFICATIONS

Item No.	Suggested Range	Setting Range	Drive (inches)	Accuracy (Note2)	Preset Accuracy (Note2)		Ratchet Teeth	Resolution	Length	Weight (g)	Approximate Range Of Applied Force (Note3) (kgf)
Item No.	Suggested Range	Setting Range	Drive (inches)	CW	CW	CCW	Ratchet Teeth	Resolution	Length	Weight (g)	Approximate Range Of Applied Force (Note3) (kgf)
WQ-30-1-BT	4.5~30 Nm	1.5~30Nm	1/4"	±1%	±1.5%	±2.5%	72	0.01 Nm	394	770	1.5~10
WQ-30-2-BT	4.5~30 Nm	1.5~30Nm	3/8"	±1%	±1.5%	±2.5%	72	0.01 Nm	394	795	1.5~10
WQ-60-2-BT	9~60 Nm	3~60Nm	3/8"	±1%	±1.5%	±2.5%	72	0.01 Nm	394	795	3~20
WQ-135-2-BT	20~135 Nm	6.8~135Nm	3/8"	±1%	±1.5%	±2.5%	72	0.1 Nm	418	898	6~43
WQ-135-3-BT	20~135 Nm	6.8~135Nm	1/2"	±1%	±1.5%	±2.5%	72	0.1 Nm	438	1114	5~40
WQ-200-3-BT	30~200 Nm	10~200Nm	1/2"	±1%	±1.5%	±2.5%	72	0.1 Nm	549	1272	7~45
WQ-340-3-BT	50~340 Nm	17~340Nm	1/2"	±1%	±1.5%	±2.5%	72	0.1 Nm	650	1470	9~62
★WQ-600-4-BT	90~600 Nm	60~600Nm	3/4"	±1%	±1.5%	±2.5%	24	0.1 Nm	940	3902	11~77
★WQ-800-4-BT	120~800 Nm	80~800 Nm	3/4"	±1%	±1.5%	±2.5%	24	0.1 Nm	1235	4695	11~75
★WQ-1000-4-BT	150~1000 Nm	100~1000Nm	3/4"	±1%	±1.5%	±2.5%	24	1 Nm	1235	4695	14~93

Note1: The accuracy range for torque is from 20% to 100% of the maximum operating value.
Note2: Accuracy (cw) means that the clockwise calibration in the factory will be based on the factory accuracy, preset accuracy is a general reference.
Note3:The applied force (kgf) = recommended torque (kgf∙cm) / effective length (cm) (distance from the center of the handle to the center of the torque application point).
Note4:Operations requiring more than 50 kgf must be performed by two people or require additional extension rods.
Note5:★ indicates custom-made products, with long lead times required.

※1 Nm=10.2 kgf-cm=0.738 lbf-ft=8.851 lbf-in

APP： https://appurl.io/fsLeJwKbtN （Please use your phone to open）

software：https://www.asmith.com.tw/en/downloads/list/6（Please use a computer to open）

Wrench operation

藍牙扳手操作

Wrench Calibration Procedure

藍牙扳手操作

Charging Cable

Rechargeable Type Features

Digital Torque Wrench - Cordless" utilizes the latest USB-C charging method that complies with EU standards.
It retains 80% of its capacity even after 300 recharges and has a battery life of up to 3 years (replaceable and serviceable).
With frequent use, it saves approximately 100 zinc carbon batteries a year, making it suitable for users who tighten screws frequently."

IC Protection with Dual Safeguards

To ensure the stability and safety of the charging and discharging process for user protection, the circuit board incorporates a series of protective mechanisms:
⚡ Over-discharge protection - It cuts off power in case of excessively low battery levels to prevent a reduction in battery lifespan.
⚡ Overcharge protection - When the battery reaches full charge, the circuit is disconnected to prevent overcharging.
⚡ Overcurrent protection - The circuit is interrupted in cases of excessive charging or discharging.
⚡ Over-temperature protection - Charging is halted if the temperature exceeds 55 degrees Celsius during the process.

Furthermore, it includes a voltage stabilization mechanism, reverse current protection, and dual-circuit protection ICs, providing you with added peace of mind during use.

The illustration of using wrench handle.

Digital Torque Wrench Demo (Please turn on subtitles )
